2009-13 2WD Ford F150 6" strut lift kit, Nitro shocks
$1,450.64
Product No
F20N-ZN
FREE SHIPPING Lower 48 States
Important Notes
* Vehicles equipped with factory powersteps will require E-Brake Relocation Bracket ZONF5608.
* Will not work with 17" wheels.
* If using 18x9 wheels with 5.5" backspace, fit the wheels before mounting to check for proper tie rod clearance. Wheel manufacturing variances may affect this clearance.
* Certain models with a 2-piece rear driveshaft may require carrier bearing drop kit ZOND5405.
* Although rare, rear driveshaft extension ZONF5601 may be required.
* Will not work with 17" wheels.
* If using 18x9 wheels with 5.5" backspace, fit the wheels before mounting to check for proper tie rod clearance. Wheel manufacturing variances may affect this clearance.
* Certain models with a 2-piece rear driveshaft may require carrier bearing drop kit ZOND5405.
* Although rare, rear driveshaft extension ZONF5601 may be required.
Quick Overview
The Zone Offroad 6" lift kit for the Ford F150 includes new coilover struts custom valved for larger tires, improved ride and optimal handling. The fully cast, CNC machined and resonant frequency tested knuckles ensure proper steering geometry while reducing installation time. These correct the tie rod and ball joint geometry with no track width change. This kit also features heavy 1/4" thick main crossmembers. The rear is lifted with a 5" dual pin block and u-bolt kit that offsets the axle closer to the center of the wheel. Rear Nitro shocks are included. Shock boots sold separately.
This lift will not work with 17" wheels. If using 18x9 wheels with 5.5" BS, fit the wheels before mounting to check for proper tie rod clearance. Wheel manufacturing variances may affect this clearance.
Covered by the 560plus Factory Protection Plus Program for vehicles less than 5 years old from the date of manufacture and the mileage is less than 60,000 miles. Click here for details.
View kit installation instructions
This lift will not work with 17" wheels. If using 18x9 wheels with 5.5" BS, fit the wheels before mounting to check for proper tie rod clearance. Wheel manufacturing variances may affect this clearance.
Covered by the 560plus Factory Protection Plus Program for vehicles less than 5 years old from the date of manufacture and the mileage is less than 60,000 miles. Click here for details.
View kit installation instructions
Required and/or Related Items
-
$71.34
-
$13.51
-
$45.89
- Make: Ford
- Model: F150
- Vehicle: 2009-13 F150 6" strut lift kit, Nitro shocks
- Drive: 2WD
- Tire Size: 37x13.50 on 18x9 rims, 5.5" BS
- Upsell: ZONF5608, ZOND5405, ZONF5601
Zone Offroad 6" lift kit fits following models:
2009 Ford F150
2010 Ford F150
2011 Ford F150
2012 Ford F150
2013 Ford F150
2009 Ford F150
2010 Ford F150
2011 Ford F150
2012 Ford F150
2013 Ford F150
